無錫市德潤輕工機械廠
供應熱水泵不銹鋼控溫對比轉鼓
價格:面議
價格:面議
品類 | 轉鼓 | 品牌 | DESH |
---|---|---|---|
型號 | GI&Phi |
性能:
*整機鼓體機架采用不銹鋼制作、使用壽命長。
*采用熱泵循環加熱,停鼓時能加熱恒溫。
*無級變速,速度快慢可調(0-12轉分)。
*自動加溫,恒溫,溫度控制正確(0-70℃±1℃)
*蒸汽加溫,更快的提高加溫速度和節省能耗(0-70℃±1℃)。
*全新快啟式鼓門,操作方便。
*加熱液和鼓內液體分離,清洗徹底,無殘液和廢渣。
*電加管使用壽命長,電機使用壽命長。
*設工作時間總定時,定時正反轉動,調節時間(0-9999)分,也可單方向轉動。
*設有夜間工作系統,在皮液過夜時可控制溫度,定時轉動、使鼓體內的皮毛及時翻動,染色更均勻,防止皮張長時間應停鼓而壓出壓紋和染色不均勻及低溫情況下過夜時測出和數據不正等情況.
properties:
* the drum body frame made of stainless steel, long service life.
* using heat pump cycle heating, stop drum can heating temperature.
* stepless variable speed, speed, speed adjustable (0-12 revolutions per minute).
* automatic heating, constant temperature, temperature control right (0-70℃±1℃)
* steam heating, improved heating speed and save energy consumption (0-70℃±1℃).
* new fast and type drum door, easy to operate.
* heating liquid and inside the drum liquid separation, clean thoroughly, no residual liquid and waste residue.
* electric and pipe service life is long, motor long service life.
* set working hours total timing, timing positive and negative rotation, the regulating time (0-9999) points, also can be single direction rotation.
* with night work system, in skin liquid for the night can control temperature, timing turn .
型號model | 規格size(mm) | 裝皮量max loading capacity | 工作轉速speed | 控溫范圍control temperature range | 電機功率motor power(kw) | 重量weigth(t) |
gi 2500 | φ2500*2000 | 1000 | 0-12 | 室溫-70℃ | 15 | 4.5 |
gi 2501 | φ2500*2300 | 1200 | 0-12 | 室溫-70℃ | 15 | 4.8 |
gi 2800 | φ2800*2500 | 2000 | 0-12 | 室溫-70℃ | 22 | 5.8 |
gi 3000 | φ3000*2500 | 2000 | 0-12 | 室溫-70℃ | 22 | 6.2 |
gi 3001 | φ3000*3000 | 2500 | 0-12 | 室溫-70℃ | 22 | 6.5 |
