筒子紗染色機 TS-TCD

YARN DYEING MACHINE

本機主要適合在140℃以下對棉、毛、麻、滌棉、滌等天然纖維 及其混紡織物的絞紗、筒子紗進行染、煮、漂白、清洗等工藝處理。

This product is mainly suitable for process treatment(such as dyeing,boiling,blanching and cleaning,etc)under140 for cotton,wool,hemp,polyester cotton and polyester fiber,etc.natural fiber,and reeled yarn cheese of their blend fabric.

技術特點 Features

1. 循環染液流量控制根據不同紗種和染色工藝要求，通過主泵變頻調速系統，達到節省能源并給予合理的流量，實現同步染色控制*佳化。

Cyclic dye flow control according to different yarn and dyeing process requirements, through the main pump frequency control system, to save energy and give reasonable flow, to achieve synchronous dyeing control optimization.

2. 結構緊湊的液流換向器，消除換向停頓，增加了循環次數，使染色更均勻。

The compact flow commutator eliminates the commutation pause, increases the number of cycles, makes the dyeing more uniform.

3. 采用高效率換熱器，換熱效果好。

The use of high efficiency heat exchanger, good heat transfer effect.

4. 低浴比設計(1:3～1:8)，節省染料、助劑和能源，減少排污量，提高經濟效益。

Low liquor ratio than the design (1: 3 ~ 1: 8), save dyes, additives and energy, reduce emissions, improve economic efficiency.

5. 可變載式紗桿，使容紗量可進行有級變換，達到固定浴比，提升加工彈性。

Variable load type spindle, so that the amount of yarn can be level change, to a fixed bath ratio, enhance the processing flexibility.

6. 快速的清洗系統，有效節省清洗時間及用水量。

Fast cleaning system, effectively save the cleaning time and water consumption.

7. 溢流式加料系統，可進行動態化料，有效控制加料的速率和量，保證均勻的上染率。

Overflow feeding system, can be dynamic materials, effective control of the rate and amount of feeding to ensure uniform dyeing rate.

8. 采用新型離心循環泵，具有高性能高效率且節省進水和排水的時間。

The use of new centrifugal circulation pump, with high performance and high efficiency and save fill water and drainage time.

標準配置  Standard configuration

 1. 機身和所有與染液接觸部分均采用高度抗腐蝕不銹鋼316制造。

The fuselage and all contact with the dye are made of highly corrosion resistant stainless steel 316.

 2. 配備機械密封裝置的高效率不銹鋼循環泵，主泵配備變頻器可無級控制流量。

Equipped with mechanical seal device of high efficiency stainless steel circulating pump, the main pump is equipped with inverter can be stepless control flow.

 3. 垂直式缸體，配備平衡重錘開關缸蓋及手動控制缸鎖，并配備安全聯鎖裝置。

Vertical cylinder, equipped with balanced hammer switch cylinder head and manual control cylinder lock, and equipped with safety interlock device.

 4. 新穎高效的管道外置式熱交換器。

Innovative and efficient piping external heat exchangers.

 5. 配備溢流式加料系統、回流系統、攪拌系統的染料桶。

Equipped with overflow feeding system, reflow system, mixing system of dye barrels.

 6. 全自動比例式升溫和降溫系統。

Fully automatic proportional heating and cooling system.

 7. 定量漸進加料系統(僅供氣墊式為標準配置)

Quantitative progressive feeding system (air cushion only for the standard configuration).

8. 標準筒子紗規格：Φ165*170mm(L），每個筒子紗按1KG/個計算。

Standard cone yarn specifications: Φ165 * 170mm (L), each cone yarn by 1KG / pcs calculation.

技術參數 Parameter
